Air Receivers - DELTA Filters & Separators Pvt Ltd

1. Decrease wear and tear on the air compressor components, capacity control system, and motor

2. Reduce excessive air compressor cycling

3. Eliminate pulsations on the air discharge line

4. Due to air expansion and cooling within the Vessel, the Receiver will separate a portion of moisture, oil, and solid particles that might be present in the air.

5. Air Receiver offers additional storage capacity to be utilized in case of additional demand and/or electrical outage

6. Wide range of models, to handle storage capacities from 20 Litres up to 5000 Litres

7. Competitive Pricing. Minimal operating/maintenance costs.

8. Email: sales@deltafilters.com

Air receivers are pressure vessels used for compressed air storage. This equipment is recommended to be used in all compressed air systems. DELTA Air Receivers are designed as per ASME Sec VIII Div 1 Code. Our Air receivers always meet or exceed this code.

DELTA Air Receivers:  are equipped with a safety valve, which is set at a pressure lower than the design pressure but at a higher pressure than the operating pressure. The safety valve protects against excessive pressure buildup within the Air Receiver. DELTA Air Receivers are also equipped with a drain valve to eliminate accumulated moisture. Further, the Receiver is fitted with a Pressure Gauge and Handhole. In the case of Vertical Models: Leg Support is provided for easier installation.

DELTA Air Receivers:  are installed after Moisture Separators and before Air Filters in case of Wet Air. Due to air expansion and subsequent cooling, the presence of an Air Receiver separates moisture from compressed air. The discharge of the Air Receiver reduces the load on Sub-Micron Filters and Dryers connected downstream. In the case of Dry Compressed Air (i.e. Post Air Dryer), a Dry Receiver is employed to provide for sudden air demand from the Plant. Contact us today for more details and a Quote

1. Housing: SA 516 Gr. 70 / IS 2062 / SA 106 Gr. B (Option)

2. Working Pressure: 1 Bar, Upto 100 Bar (Option)

3. Drain: Manual (Std.) , Automatic Drain (Option)

4. Email: sales@deltafilters.com

1. Application: Automatically discharge water from compressed air/gas lines

2. End Connection: 1/2" BSP with manual override at bottom

3. Installation: Drain point of Air Receivers, Filters, Moisture Separators, Air Receivers.

4. MOC: Die Cast Aluminum with SS304 Float assembly

5. MOC: No Air Loss, Highly Reliable Design

6. Working Pressure: 0 to 15 Bar

7. Email: sales@deltafilters.com
